Includes 4 - Prismatic 3.2V 206Ah LiFePO4 Cells with Daly 4S 150A BMS, 3 Heavy Duty Bus Bars, 8 Lug Nuts, 2 - 36" Zip Ties, and 1/2" x 36" 3M VHB Tape and instruction manual.
Built with quality materials and easy-to-use Gauntlet Battery rechargeable prismatic cells can be mounted in any orientation, even upside down, and weighing only 36.8 lbs. It is half the weight of their lead-acid/ AGM battery counterparts.
Battery Specifications:
- Nominal Voltage: 12V
- Capacity: 206Ah
- Weight: 36.8 lbs, (16.6 Kg)
- Size: 10”x7”x8.5” (l x w x h)
- Cycle Life: 5000/5 years
Prismatic Cell Specifications
- Nominal Voltage 3.2V
- Capacity 206Ah
- Core size 6.81" x 1.88" x 5.2" (lxwxh)
- Cell Weight 5.0 lbs
- Charging Current; Standard Charge 0.5C
- Max Discharging Rate 1C Continuous
- Cut-off Voltage; Charging 3.65V Discharging 2.5V.
- Recommended SOC Window SOC 10%~90%
- Internal Resistance 0.4mΩ Fresh Cell, 30% SOC
- Working Temperature; Charging 0~60°C Discharging -30~60℃,
- Storage Temperature; ≤1 month: -10–45℃, ≤3 month: 0–30℃, ≤6 month: 20±5℃
Battery Management System (BMS) Specifications:
- Power balancing 2.65V
- Balance Release Volt 2.65V
- Balance Current 40+/-5mA
- Over-Discharge Detect Volt 2.8+/-0.05V
- Over-Discharge Detect Delay 0.5V
- Over-Discharge Volt Release 3.0+/-0.05V
- Over Current Detect Volt 150mV
- Over Current Detect Delay 9MS
- Short Circuit Detect Delay 250uS
- Main Circuit Resistor ≤10mΩ
- Working current ≤100uA
- Working Temp Range -20/+80ºC
Additional Applications:
Lithium-Ion prismatic deep cycle battery 12V 206Ah is ideal and preferred for the following applications. - Solar & wind power
- Off-grid applications
- RV, Marine, Golf carts
- Electric vehicles
- DIY electric storage
- Backup power systems
- Emergency lighting systems
- Handling equipment
- Uninterrupted standby power supply systems
